A pre-authentication and light active-recon tool for OPC-UA servers: enumerate endpoint security configuration, test whether anonymous or credentialed access actually works, and scan for tags that are writeable by the authenticated session.
Only use against systems you own or are explicitly authorised to test.
The source code can be found on the (github)[https://github.com/chrisdinozzi/opcua-recon] repo for this project.
Features
- Enumerate endpoint security settings (security mode, policy, advertised auth methods)
- Confirm whether anonymous access works
- Confirm whether supplied credentials work
- Scan for writeable tags (advertised
UserAccessLevel, not confirmed by writing) - Export writeable-tag findings to CSV
- Mass-scan a list of targets from a file
Requirements
- Go 1.21
go mod tidyto fetchgithub.com/gopcua/opcuaandgithub.com/fatih/color
Limitations
- Write-tag scanning currently only runs against
SecurityMode: Noneendpoints - Credential probing does not yet support client-certificate authentication (see TODO)
Usage
| Flag | Description |
|---|---|
-endpoint |
Full OPC-UA endpoint URL, e.g. opc.tcp://10.0.0.10:4840 |
-ip |
Server IP (combine with -port) |
-port |
Server port (default 4840) |
-ip-file |
Newline-delimited file of targets for mass scanning. Each line may include a port (10.0.0.10:18889); if omitted, -port is used |
-probe-anon |
Actively attempt an anonymous session to confirm it really works |
-probe-creds |
Attempt authentication with -user/-pass |
-user |
Username for credentialed auth |
-pass |
Password for credentialed auth |
-probe-write |
Scan for tags writeable by the current session (anonymous or credentialed) |
-batch-size |
Nodes read per batch during the write-tag scan (default 50; 1 streams one at a time) |
-rewrite-host |
Replace a server’s advertised endpoint host (often an internal/NAT address) with the host you actually dialled |
-output-file |
Append writeable-tag findings to this CSV file |
-verbose |
Enable diagnostic output |
CSV output format
When -output-file is set, each writeable tag found is appended as a row:
Endpoint, SecurityMode, SecurityPolicy, AuthMethod, NodeID, BrowseName, AccessLevel, Value
IP file format
One target per line; port optional, otherwise defaults to -port:
10.0.0.10
10.0.0.11:99009
172.16.3.4
Build
go install github.com/chrisdinozzi/opcua-recon@latest
Then run examples below with ./opcua_recon instead of go run opcua_recon.go.
Examples
Scan an OPC-UA Server by Endpoint
go run opcua_recon.go -endpoint "opc.tcp://10.0.0.10:4840"
Scan an OPC-UA Server by IP and non-standard port
go run opcua_recon.go -ip "10.0.0.10" -port 18889
Scan an OPC-UA Server by IP and check if anonymous access works
go run opcua_recon.go -ip "10.0.0.10" -probe-anon
Scan an OPC-UA Server by Endpoint and check if credentials access works
go run opcua_recon.go -endpoint "opc.tcp://10.0.0.10:4840" -probe-creds -user "user" -pass "password"
Scan an OPC-UA Server by Endpoint and check if anonymous access works, and look for anonymous writeable tags, output to file
go run opcua_recon.go -endpoint "opc.tcp://10.0.0.10:4840" -probe-anon -probe-write -output-file out.csv
Scan an OPC-UA Server by Endpoint and check if credentials access works, and look for writeable tags for said credentials
go run opcua_recon.go -endpoint "opc.tcp://10.0.0.10:4840" -probe-creds -user "user" -pass "password" -probe-write
Scan an OPC-UA Server by Endpoint that is behind NAT/Firewall, or has a hostname different from the user provided
go run opcua_recon.go -endpoint "opc.tcp://123.45.67.89:4840" -rewrite-host
Specify a scanning batch size for writeable tag scan. useful for slow servers (slower the server, lower the batch count)
go run opcua_recon.go -endpoint "opc.tcp://123.45.67.89:4840" -rewrite-host -probe-anon -probe-write -batch-size 10
